HOBBYWING FlyFun 10A V4 - 80020580
Price:
USD$0.00
Brand:
Hobbywing
Model:
HW-80020580
Please kindly input your name and email address, we will inform you once we have the restocking.
Or you may find similar product under the
category
Write a review

Reliable Performance with Hobbywing FlyFun 10A V4 ESC

The Hobbywing FlyFun 10A V4 ESC is engineered to deliver exceptional performance for a variety of RC aircraft, including fixed-wing models, helicopters, and multirotors. This electronic speed controller features imported components and a PCB with extremely low impedance, ensuring excellent current endurance and high reliability.

Advanced Programmable Features

Equipped with a range of programmable parameters, the FlyFun 10A V4 can be easily adjusted using a LED program card. This flexibility allows you to customize your setup to suit different types of aircraft, enhancing your control and performance on the field.

Comprehensive Protection Mechanisms

To ensure longevity and safety, the FlyFun 10A V4 includes multiple protection features. These safeguards protect against abnormal input voltage, ESC thermal issues, throttle signal loss (or Fail Safe), and low voltage cutoff, effectively extending the service life of the ESC.

Specifications

  • Type: Brushless (BL)
  • Voltage: Regular
  • Continuous/Peak Current: 10A/12A
  • Input: 2-4S LiPo
  • BEC Output: Linear mode: 5V, 1A
  • Output Wires: Blue-20AWG-100mm*3
  • Input Connectors: No
  • Output Connectors: No
  • ESC Programming via Transmitter: Supported
  • LED Program Card: Supported
  • LED Program Box: Not Supported
  • LCD Program Box: Not Supported
  • WiFi Module: Not Supported
  • Program Port: Program/Throttle Wire
  • Firmware Upgrade: Not Supported
  • Size: 38.0x18.0x6.0mm
  • Weight: 10g
Yes, the FlyFun 10A V4 is designed to work with various aircraft types, including multirotors.
The FlyFun 10A V4 supports programming via a LED program card but not through a program box.
