The XRotor Micro 30A BLHeli_32 DShot1200 30901077 produced by Hobbywing, is classified in R/C Models - System - Drone System
High Performance Hardware &
Original Third-generation BLHeli_32 Firmware
The use of superior 32-bit ARM microprocessor (which runs at 48MHz),
brought in top quality MOSFETs (Fairchild) & ceramic capacitors, 3-in-1 drive ICs,
3-ounce copper, 4 levels of PCBs, together with third-generation BLHeli (BLHeli_32 firmware)
produces an ESC with an increase of functions & better performance especially for FPV drones.
Hardware Generated PWM & Damped Light Mode
The ESC firmware utilizes equipment produced engine PWM for smooth throttle response and quiet
procedure. Damped light does regenerative breaking, causing very fast motor retardation, plus it
inherently also does active freewheeling.
Multiple Programmable Items
The initial BLHeli_32 firmware enables users to get in touch four
ESCs toward FC flashed aided by the Cleanflight/Betaflight
firmware via sign cables (in the ESCs) setting basic
parameters associated with ESCs simultaneously, upgrade the firmware
or adjust advanced level parameters online as well.
Multiple Protections
Multiple protection functions like motor
lock-up protection, temperature protection,
low RPM energy security, low-voltage
security and present protection efficiently
prolong the service life regarding the ESC.
Light-emitting Diode Indicator (only the XRotor 40A
BLHeli_32 has it) & Beacon Functionality
The light color associated with Light-emitting Diode indicator in the ESC is adjustable.
The Beacon functionality, that may drive the motor to beep in the event that throttle sign has
been zero for a given time, effectively helps finding lost crafts.
Specifications
- Cont./Peak active : 30A / 50A
- LiPo Cells : 2-5S Lipo
- BEC production : No
Wires & Connectors
- Output Wires : No cables but solder tabs
- Input Connectors : No
- Output Connectors : No
- Firmware : BLHeli_32
- ESC Programming : Supported
- Stick Programming : BLHeliSuite
- DEO : Supported
- Throttle Range Calibration : Supported
- Oneshot125 Mode : Supported
- Oneshot42 Mode : Supported
- MultiShot Mode : Supported
- Timing : Supported
- Motor Rotation : Supported
Size & Weight
- Size : 23.8x14.5x5.8mm
- Weight : 6g
