The MINI-Z AWD SUBARU IMPREZA 22B-STi Version Blue produced by Kyosho in 1/27 scale MA-020 series assembly kit, is classified in R/C Models - On-Road - Mini-Z
To create its dynamic performance to even more drivers, the MINI-Z AWD is now obtainable in a Readyset. The MA-020 chassis features VCS (variable camber suspension system) in the front that optimizes camber change with suspension stroke and a specially designed circuit board. The chassis design permits space for installing the optional gyro unit(offered separately). The gyro could be modified by turning a tiny volume regarding chassis to reflect the amount of steering correction responding to alterations in framework position, enabling beginners right through to experts to push for their full potential. Fully fitted down with accuracy ball bearings, the high drive effectiveness of this MA-020 chassis is complimented in the Readyset by the initial scale body and 2.4GHz Syncro KT-531P R/C system that requires no frequency band environment; all at a great value cost. Just set the batteries to enjoy the thrill of drift driving with all the included group of drift tires. The chassis works with with the majority of ASC MINI-Z bodies (additional components maybe needed for someone designs). The MINI-Z AWD guarantees a distinctive realm of dramatic racing action for you yourself to experience and luxuriate in.
● MINI-Z AWD Readyset predicated on MA-020 chassis.
● Special circuit board updated with optimized steering control system.
● Chassis features gyro sensitiveness adjustment function.
● Drift tires are installed as standard.
● Readyset calls for only batteries become ready to use it!
● Features 2.4GHz Syncro KT-531P transmitter that needs no setup of regularity bands.
● Factory completed human body comes with display model quality finish.
● Features VCS (variable camber suspension) that adjusts camber according to suspension swing.
● Coil springtime on front suspension system can be easily replaced without tools.
● number of optional components is available to be installed.
● Note) Optional ICS cannot be utilized. Also, this model is especially designed for the KT-531P transmitter. It's not compatible with the KT-18, KT-19, EX-5UR ASF, EX-6 or EX-6R transmitters. It is just compatible with the special gyro product (sold individually).
In 1998, Subaru produced 400 units associated with the restricted edition 22B-STi to commemorate its three consecutive WRC (World Rally Championship) victories reached the prior year. Despite being a road vehicle, the restricted edition is made in image of the WRC automobile with features such as for instance front and rear blister fenders and big rear wing.
Includes stylish design of Syncro KT-531P transmitter. Features steering / throttle trim plus twin rate modification of steering angle and control the blinking speed of optional LEDs. In addition, the transmitter has an exercise Mode function which limits rate of the vehicle for easy learning (default environment during shipment is Training Mode).
Unique AWD Sports framework is dependant on the MA-02 chassis and features the RA45 unit.
Features VCS front suspension that optimizes camber change in concert with suspension system stroke. Replacement of front suspension coil springs is not hard without tools required.
Equipped with strut-type rear suspension system.
Full bearing specs consist of 14 ball bearings.
Built with drift tires as standard.
Loaded with special mount space and gyro adjustment amount for the optional gyro product (sold separately)
TECHNICAL INFORMATION
- Length 161.0mm
- Width 70.0mm
- Height 51.5mm
- Wheelbase 90.0mm(M)
- Tread F : 58.5mm R : 58.5mm
- Tire F : 25.0mm x 8.5mm R : 25.0mm x 8.5mm
- Gear ratio 7.23 : 6.38 : 5.71 : 5.97 : 5.34 : 4.97 : 4.5:1
- Front Wheel Offset Narrow +1.0mm
- Rear Wheel Offset Narrow +1.0mm
- R/C System Syncro KT-531P
- Weight 170g
KIT CONTENT
- R / C unit integrated complete chassis
- Painted and marked complete body
- Syncro KT-531P transmitter
- Mini pylon
- Pinion gear (15T, 17T, 19T, 21T)
- Spur gear (27T, 29T, 31T)
- Spare nut
- Wheel wrench
- Pinion removal device
REQUIREMENT TO PERFORM
- AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
- AAA-size alkaline batteries x 4 for transmitter
