Serpent SER600039-R Serpent Cobra E-Truggy RTR red  [SER600039-R]

Serpent SER600039-R Serpent Cobra E-Truggy RTR red

Price:

USD$559.65

Brand:
Serpent
Model:
SER600039-R
Condition:
Brand New
Write a review
The Cobra E- red produced by Serpent in 1/8 scale AWD drivetrain RTR (Ready-to-Run), is classified in R/C Models - Off-Road - Truggy - Electric Powered
  • Introduction

    The Serpent Cobra E-Truggy in RTR trim is a great basher kind vehicle that may just take a lot of beating and its particular also an excellent package to begin real race ! In line with the Cobra E-Truggy this has the outright rate, great management, reliability, rigidness and durability you need.

    The RTR package is truly dialed:
    -factory put together racing chassis
    -prepainted and precut low type truggy human body and big composite backside wing
    -premounted truggy tyres/wheels/inserts
    -pre-set 4S to 6S capable waterproof 150A speedo ( DragonRC)
    -2000kv brushless longbody engine (DragonRC)
    -Digital 2.4ghz transmitter (DragonRC)
    -Metal gear servo 16kg ( DragonRC-Savox)
    -3 oilfilled geardifferentials
    -Big bore shocks with plastic dustboots and machined aluminium shocktowers
    -Spring steel transmission components and turnbuckles, front side and rear cvd driveshafts
    -Front and back anti-roll bars
    -Large battery-cases with effortless felcron straps
    -Machined aluminium chassisplate
    -Fully ballraced
    -Batteries the vehicle and transmitter aren't included

    The bodyshell is available in orange, red, green, blue and red, also an obvious type.

    Serpent offers numerous optional components with this automobile to further improve performance, lighter or for even nicer looks.

  • Main features

    Car
    Fully expert pre put together and pre-set chassis and electronic devices.

    Transmitter
    DragonRc 2.4 GHz steeringwheel kind transmitter with plenty settings and good range. Includes little and light receiver.

    Speedo
    DragonRC waterproof speedcontroller with a huge 150A capacity to control the brushless engine and 4S or 6S battery pack power

    Motor
    DragonRC longbody 2000kV brushless engine with effortless colorcoded connectors

    Body
    Prepainted and pre-cut low e-Truggy human body, in 4 primary colors orange, red, Green and Blue. ( additionally clear one available as optional)

    Tyres
    Premounted race ready tyres / tires with soft compounds and pintype profile for amazing grip.

    Chassis
    Very slim 3mm 7075T6 aluminium framework, with machining regarding top face making it lighter in strategic areas and to get a handle on flex. Kick-up front for proper landings. Angled side to increase cornering clearance, and secure and simple mounting side guards with 5 screws. Countersunk holes, pouches to put the suspension brackets. In general the Truggy is designed to keep carefully the weight really main and towards the centerline as you possibly can, to generate an excellent general balance.

    Side guards / battery trays
    Durable shaped composite part guards / battery pack trays that proceed with the line of the chassis, and mount with 5 screws each part. Front and sides sufficient to help keep the dirt away. The guards/trays create many stability. The batteries are installed in longtudinal fashion, maintaining the weight low inside vehicle. The battery trays features user friendly Serpent noticeable felcron TM straps to secure the batteries in position. Fits 2S and 3S batteries.

    Motormount:
    The engine is positioned within the most optimal place within the automobile, keeping motor-forces and transmission components / alignment at heart. Only one-screw is needed to secure the BL motor, inside nicely created durable machined aluminium motormount. Space for extra motor-cooling available as needed. The room the motor enables mounting all popular buggy and (monster)truggy motors.

    Composite chassis braces
    Allows the chassis to flex which helps enhance bump handling. Front and rear.

    Front bumper
    Nicely curved front bumper, identical to regarding the Cobra buggy, to safeguard the leading anti-roll bar, suspension system brackets, and moves inline with kick-up framework front for safe landings.

    front side suspension
    Very long and durable composite lower wishbones, combined with upper spring-steel trackrods. 2 lower shock-mount jobs. Downstops may be used as required. Pivotball type anti-roll club rods.
    .
    Front steering / servo saver / angled
    Innovative angled front side steering set up to reduce the angle of distinction between the full total caster and steering airplane. Therefore you'll have less bump steer and a truer steering Ackerman through the complete range of suspension.

    Adjustable springtime loaded servo-saver system with interchangeable Ackermann plates. Because of the design associated with the steering bell cranks when changing the Ackerman you won't should adjust your steering tie rods. You just will simply need to adjust your end points on your own radio.. Very easy to gain access to and set-up.

    The Inboard Bell crank keeps the lever and linkage in the vehicle. It's going to help with preventing harm to the steering system. Zero scrub radiuses on steering knuckle, assists in easing the jacking impact developed by your steering knuckle offset. It gives a far more direct fell while keeping the vehicles chassis more degree while turning.

    The front roll center may be changed quickly by going the steering knuckle shims for their appropriate locations.

    Topped of with a good composite top-plate.

    Front steering-block / c-hubs
    Very durable front side steeringblock / C-hub construction .

    Drive-shafts
    very long and lightweight spring steel devices with pressed in metal pins, laser-engraved. Exact same size front side and rear.

    Wheel-axles / wheel-nut
    Serpent springtime metal threaded wheel-axles with lightweight grey anodised aluminium wheel-nuts to keep the huge truggy wheels/tyres on course.

    Captured universal joints
    Guarantees you are going to finish a race without loosing a pin or set screw. All parts, axles and drive train elements have capture pins

    Front shocktower
    Light, strong and durable machined 5mm aluminium devices with 5 positions for shockangle.

    Shock-set front side and rear
    16mm big bore shocks, with difficult anodized precision threaded shock-bodies. Shockboots in silicone rubber to keep the dust away . Chromed shock-shafts for supersmooth shockaction . The larger o rings offer less general stress and a better seal without dragging regarding shock shaft.

    Suspension brackets
    The hinge-pins / hingepin balls are captured in durable composite suspension brackets . These capture the nylon roll-center inserts.

    Anti-roll club / anti-roll club linkage with pivotball
    The anti-roll pubs front and back are made of good quality unique spring metal, and so are captured on diff-cased in ballbearing for perfect guidance and control.

    Receiver box / servo mount / speedo mount
    Composite one piece radiobox to securely mount servo� s, speedo and receiver. For maximum stability the light receiver fits the top-case effortless, with a small opening to allow cable to protrude. The speedo seats suprisingly low on a plate just above the chassis, therefore quick cables can be used to the motor. The servo is installed in a vertical fashion.

    Central diff
    Optimised central gear-diff with 50T super-hard spur-gear . Very small, compact design to lessen rotating mass on max.

    Transmission shafts
    Durable but light and thin Serpent spring metal, laser etched shafts.

    front side and back diff
    Optimised gear-diff with superhard spur-gears . Tiny, compact design to reduce rotating mass towards the maximum. Exact same version front side and rear. Diff coupler in springtime metal seated in large barings for durability.

    Rear shocktower
    Light, strong and durable machined 5mm aluminum product with 5 positions for shockangle.

    Rear uprights
    Durable composite back uprights with 3 camber positions

    Suspension brackets rear
    Durable composite devices with eccentric inserts to alter set-up.

    Rear wing mount
    The composite rear wing mount, allows to alter the angle regarding the back wing.

    Rear wing
    Two phase high down force wing, has two quantities of angle, which also includes 2 fins. Helps improve down force and right line capability

    Bodymounts
    Nylon bodymounts with wider seating for the human body, firmly fastened on shocktowers.

    Super Minimal profile e-Truck Body
    Improves appearance as well as keeps the profile minimum. Comes precut and prepainted.

    Decals
    Applied to your body.

    Oils / grease
    Car is assembled with a high quality silicone oils for the diffs and shocks and black oil. Threadlock used in which needed.

    Manual
    Full color manual showing the vehicle, specifications, recommendations and exploded views. The transmitter and speedo have little separate manuals included.

    Box
    Full color protective field to re-use for car transportation or tyres.
