Serpent SER903018 Viper 989 1/8 GP [SER903018]

Price:

USD$641.25

Brand:

Serpent

Model:

SER903018

Not Available

Please kindly input your name and email address, we will inform you once we have the restocking.

Or you may find similar product under the
R/C Models - On-Road - Touring Cars - Nitro Powered category

Write a review

alt="Serpent SER903018 Viper 989 1/8 GP" title="Serpent SER903018 Viper 989 1/8 GP"

Description

The Viper 989 GP produced by Serpent in 1/8 scale Touring Car series AWD drivetrain assembly kit, is classified in R/C Models - On-Road - Touring Cars - Nitro Powered

The Serpent Viper 989 could be the latest growth of Serpent regarding 1/8 fuel market.
Serpent was the driving force for many years while the Viper 989 could be the latest interpretation of a top performance competition car according to that experience, combined with latest insights on weight, fat circulation and flex.
As the inventor associated with the Centax clutch, the 2-speed gearbox and lots of other items being now industry standard, we also incorporated some new solutions regarding suspension system.

Another major point of development was to reduce fat, reduced total of vibrations and easy set-up and maintenance.
Ultra-narrow chassis with improved flex characteristics. The framework is milled down in less load-stressed areas making it as light that you can whilst still being stay rigid in areas in which needed.
We kept the possibility to possess a weight inside very base which will be effortlessly adjustable inside it’s position.
at exactly the same time we improved the way in which it really is it mounted to reduce vibrations by utilizing a carbon fat connection which can be installed in anti-vibration rubbers.
We also have added 2 more areas for another weight, one underneath the motor and another one underneath the servosaver.

The central fat connection allows making use of max 3 loads

All loads are installed as low as feasible to boost the center of gravitiy
The one-piece plastic radiomount is changed by a 2-piece aluminium construction. It is lighter compared to synthetic one, and at the same time frame it improves the flex faculties while the precision of mounting the radioplate.
The back bulkheads are now also attached to the rearplate to boost the stiffness plus decrease vibrations.
The bulkheads are machined excessively for an ideal balance between weight and strength
Their shape now permits removing the rear solid axle without elimination of the 2-speed shaft and belt
The brake now features a 2.5mm thick disk with improved ventilation and stopping security

The pulley adapter is a much lighter construction for better inertia and improved acceleration
A new shorter interior gear ratio of 2.4 assists acceleration and escalates the active selection of the general gear ratio. Using 19/24 now could be just like 18/23 on 988.

additionally the overdrive changed somewhat to have the perfect rear/front drive balance with ENS and EFRA give fully out tires
New part belt tensioners improve clearance aided by the motor manifold.
it decreases vibrations regarding sidebelt.
Adjustment is easily done regarding midshaft
The new super-light midshaft set up additionally acts as adjustable gear tensioner along with pipe wire holder
The completely new gearbox has less inertia versus one from the 988. This improves acceleration.

Despite being lighter it includes brand new features to enhance reliability and consistanty
A much longer ramp for the roller avoiding locking associated with 2nd gear even with extortionate wear on the shoes
M4 setscrews for gap modification to simply help keeping the gap constant
2 bearings inside second gear “bell” for better truth of rotation and balance
Easy access for adjustment from the outside
2nd gear adapter is locked in position to avoid binding and deliver constant performance of motor and gearbox
New shaped fueltank attached to top of the radioplate.
The brand new tank is more consistent in adjustment no matter if it is full or very nearly empty.
The brand new tank seal keeps an increased pressure and keep things clean and dry
The limit associated with tank is higher allowing even faster refueling.
The number of the tank is 125cc and has to be adjusted by the user to master volume inside the guidelines through inserts
New superlight, one-piece bumper for improved aerodynamics.
No inserts any longer to keep it easy. Extortionate screening of various forms lead united states to this design to really have the most useful balance of front end grip on high and low rate and hairpins
New mounted rear framework stiffener to allow for easier removal of the radioplate
New method of mounting of this servosaver. In the event that radioplate just isn't mounted, the servosaver nevertheless stays in place
New shaped radioplate. This shape is found to deliver the best flex characteristics
New improved shockabsorbers for the ultimate hold

The solitary most important new function are probably the shock-absorbers. Plenty of attention has been payed to attenuate friction and jamming.
evaluating has additionally shown that a slightly smaller bore increases results.
on back associated with the car we also increased the total size for extra stroke and better progressivity
The piston is fixed onto the shaft with a nut. No clipses or shims.
On top of this we payed some awareness of the bottom seal. 2 X-rings and an extended bushing provide that additional little bit of low-friction sealing that keeps the oil inside additionally the dirt outside
As an alternative the 989 offers a heave-damper setup inside front side as well as the rear.
In because of this it is possible to alter heave changes pretty much independent of roll changes.
For instance you are able to have a really light roll damping coupled with a tremendously high heave damping, something is not possible with a classic suspension system.
The next damper may be used to just alter the damping faculties without a third spring, but in addition to incorporate a spring to improve springtime prices for heave
leading and rear heave sets can be obtained as an option.
Other main specifications

- 4wd belt-driven race vehicle
- Serpent spring metal axles with quick change system for the wheels
- front side and back springtime steel cvd shafts
- NSK bearings for the transmission
- minimal friction belts and ball raced belt-tensioner
- Ebony anodized front shaft with one-way bearings and slim back solid axle
- super low inertia 2-speed gearbox
- separate suspension with hydraulic low-friction shock absorbers
- Ball raced front and back anti-roll bars
7075 T6 Aluminium 5mm chassis dish
The 5mm aluminium chassis has perfect symmetrical form even for flex and weight circulation. The ultra-narrow chassis is quite light, although it still remains strong in critical places. The Viper 989 logo design is laser etched.
The newly developed front bumper is a tremendously light and simple to utilize design.
The strong aluminium front human body posts are eccentric, allowing motion of human body several mm forward and backwards to optimize steering and downforce.
The steering blocks, which are equal left and right, provide a method to change the axle position to a “trailing” or “leading” position, while the capability to change the kingpin-inclination and offset. This allows numerous options to fine tune steering stability in all phases of corner. The steering block features an aluminium dish in order to connect the spring metal track-rods. They have 2 Ackermann choices.
Optional carbon fibre disks may be mounted on the side of steering blocks and uprights for aerodynamic adjustments.
The long durable front lower wishbones have been in a new hollow kind design with shut base for improved aerodynamics and have now separate top mounted moulded inserts. An aluminium shock mount dish is screwed on the lower wishbone. This permits the surprise attachment indicate be placed further outwards enhancing shock motion. The leading reduced hands are mounted to the front brackets with nylon holders. The kit includes 2 versions: in and out. This system also allows quick and easy front drive shaft maintenance.
The remaining and right interchangeable upper arms are mounted with 3 position nylon suspension pin inserts. The 3 place inserts allow camber-change changes and tend to be held set up by the anodized aluminium top brackets. Below the top brackets, spacers may be used to alter their angle or height. Caster is adjusted with videos regarding upper pivot pins. Exactly the same videos may applied to the low pivot pins to alter wheelbase.
The cable kind front side anti-roll club is ball raced. It is possible to alter and adjust because of the available front end design. The standard wire is 2.5mm and 2 optional thicknesses can be obtained. The pivot ball link system directs the suspension motion to the club and permits easy tweak modification.
The steering blocks are connected to the hands with springtime metal 8.5mm pivot balls, which operate really smooth and well protected in nylon cups, as they are easy to adjust with a 2.5 hex tool.
The black anodized aluminium front axle has Japan made one-way bearings. Spring steel drive cups hook up to the long and slim spring-steel drive shafts with CVD system. The ball raced spring steel wheel axles have actually aluminium quick-change levers. The available front end design permits extremely fast and easy elimination of the front axle and driveline parts.
The central mounted seervosaver allows simple and fast Ackermann modification. The servosaver features a top mounted insert which can be used in 3 jobs. Another 2 Ackermann roles can be found regarding steering obstructs.
The tail construction with aluminium brackets is a tremendously open design, which allows for simple of maintenance and cleansing. Dis-assembly calls for the removal of just a few screws. Changing a belt if needed, is a simple task. The eccentric bearing holders in the rear shaft allow adjustment of gear stress. The whole rear end may be removed as you device from framework by elimination of only a few screws.
The wire kind backside anti-roll bar is ball raced. It is installed in back bearing blocks and it is very easy to alter and adjust. The standard wire is 2.5mm and 2 optional thicknesses can be obtained. The pivot ball link system directs the suspension movement toward bar and allows easy tweak adjustment.
The slim solid rear axle in Serpent spring steel has a lightweight 9mm wide 48T pulley. The axle has a double slot for the driveshaft pin for lightness and endurance. Spring steel, CVD kind, drive shafts connect a corner shaft to spring metal wheel-axles with aluminium quick-change levers. A tremendously durable and long-lasting drivetrain.
The brand new back lower wishbones have a hollow style design with shut bottoms for aerodynamics and separate top mounted moulded plates. The reduced rear hands contain the link for the backside anti-roll bar together with aluminum mounting full bowl of the rear shocks. This dish moves the shock mounting position towards the exterior for improved geometry. Nylon videos are utilized in the lower rear pins to alter wheelbase.
The durable composite uprights contain the ball raced wheel axles, with aluminium quick-change levers. On top of the up-right spacers could be added under the pivot ball to improve roll centre and camber change.
Optional carbon fibre disks could be mounted on the medial side of the uprights for aerodynamic reasons. The trunk uprights are attached to the arms with springtime steel 8.5mm pivot balls, which run really smooth and well protected in nylon cups, and therefore are simple to adjust with a 2.5 hex tool.
The adjustable back upper camber links mount to a 4 position back carbon fiber camber plate.
A corner floating body mount which can be installed on the up-rights with 2 arms is centred by a carbon-fibre and steel guider. The mount has 4 positions on each part available, depending on human anatomy shell used and traction available. The threaded holes on end of the human anatomy mount give the option to add further body-supports.
Optionals
A big selection of optional parts can be obtained to further improve performance, speed, weight and appears.
www.serpent.com/903018

Communications
- web site
- Promopage
- Facebook web page
- Viper 989 Facebook individual group
- Serpent Advanced individual Manuals pages
- YouTube video’s
- Online set-up sheets
- Support from suppliers, dealers and team motorists around the world

Merchandising
a fantastic selection of tops, sweaters, coats, caps, bags, tools and decals.

Design
Serpent Viper 989. Designed by Michael Salven.
With great help from all team-drivers and 988 motorists!
