Tamiya 58489 - 1/10 RC High Performance 4WD Off Road Racer Avante 2011  [58489]

In March 1988, Tamiya circulated a power R/C 4WD racing buggy called the "Avante" and possesses since become a special device in Tamiya's R/C history. The machine featured an original shaft-driven 4WD system that was taken from Tamiya's first 4WD R/C buggy, the Hotshot. It also featured an extremely advanced design including a FRP double-deck framework design, longitudinal engine & battery pack positions, and a formula-type body with framework fairing. It absolutely was prepared with revolutionary elements including a compact gearbox with 3 little planetary gears, a center diff to improve security, a totally adjustable suspension, and cam-lock wheel caps.

The Avante was a distinctive R/C device which featured an innovative design. After twenty years, a few of the Avante's mechanisms have grown to be standard features on modern R/C automobiles. The greatest pure racing buggy comes back last year.

Tamiya has given the Avante (2011) the unique re-release therapy like other re-released buggies for instance the Buggy Champ and Hotshot. The following is a short introduction regarding the improved points.

• Principal framework product was changed from FRP to carbon fibre. Original FRP upper/lower decks have already been replaced with 2.0mm dense carbon fiber decks to help expand increase framework power and rigidity. Chassis layout is optimized for installing modern R/C gear.
• Carbon Fiber Rear Damper Stay back damper stay is thicker versus initial and its own material has also been changed to carbon dietary fiber. Left and right remains are linked to further increase rigidity.
• Assembly Universal Shafts WO universal shafts are employed for both front and back to reduce friction loss.
• Easier Damper repair The gold-colored oil damper cylinders function base caps for easier upkeep including replacing o-rings.
• Durable Polycarbonate Body Shell the human body, wing, and framework fairing have actually been made with polycarbonate for superb off road durability.
• Wheel Axle/Clamp Type Wheel Hubs Wheel axles happen changed to standard pin-secured kind. Along with aluminum wheel hubs, secure wheel attachment is achievable. The hex wheel hubs help attachment of off road wheels such as Item 53880 Large Dish tires (4WD/Front, 62/25) and Item 53881 Large Dish Wheels (back, 62/35) in addition to the initial cam-lock kind tires.
• Duralumin front knuckles the first die-cast front knuckles happen replaced with duralumin knuckles to help increase durability and strength. New knuckles function similar shape as the original.Compatible with a wide array of battery packs. The Avante (2011) is compatible with a wide range of Tamiya battery items such as for example Ni-Cd, high-capacity Ni-MH, and lightweight LF battery packs.
• Latest R/C techniques The Avante is compatible with Tamiya R/C systems such as the 2.4GHz systems.
• The Original Packaging is also Revived! The package for this re-release model is sold with equivalent design and proportions since the original Avante. In addition, similar to the initial Avante, all components are stored in blister packages.
• The "Avante" logo design and rear wing sticker will remain the same as the original. Other stickers will likely to be of a brand new Tamiya design.

Specs:



• Length: 420mm
• Width: 240mm
• Height: 115mm
• Wheelbase: 260mm
• Tread (L/R): 200mm
• Minimum Ground Clearance: 40mm
• Body weight: 1300g
• Double-Deck Frame
• Tires (F/R): 38/88mm
• Polycarbonate Body
• F/R Multi-Link Suspension
• F/R Metal Oil Dampers
• Gear Ratio: 1:8.33

Features:



• Mini resin bumper.
• Front double wishbone suspension system.
• Radius arm protector.
• Front stabilizer.
• Front strut towerbar for enhanced rigitity.
• Front C.V.A. oil damper with tapered coils springtime.
• Pin increase tire.
• Internal sponge.
• Cam-loc wheel.
• Steering tie pole.
• Universal joint.
• Front gearbox features compact planetary differential w/ steel pinion gear.
• Carbon top deck, part of the double-deck framework design.
• Steel propeller shaft.
• Steering servo (maybe not included).
• Polycarbonate undertray.
• Longitudaly-mounted engine.
• Receiver (not included).
• ESC (included).
• Rear gearbox upper access hatch.
• Back steel C.V.A. damper product.
• Rear strut tower.
• Back double wishbone suspension.
• Rear stabilizer.
• Adjustable wing mount.
• Polycarbonate human body.
