Tamiya 58600 - 1/10 TT-02 Type-S Chassis Kit  [58600]

Tamiya 58600 - 1/10 TT-02 Type-S Chassis Kit

Price:

USD$126.80

Brand:
Tamiya
Model:
58600
GTIN:
4950344586004
Condition:
Brand New
( Low Inventory )
alt="Tamiya 58600 - 1/10 TT-02 Type-S Chassis Kit" title="Tamiya 58600 - 1/10 TT-02 Type-S Chassis Kit"
alt="Tamiya 58600 - 1/10 TT-02 Type-S Chassis Kit" title="Tamiya 58600 - 1/10 TT-02 Type-S Chassis Kit"
alt="Tamiya 58600 - 1/10 TT-02 Type-S Chassis Kit" title="Tamiya 58600 - 1/10 TT-02 Type-S Chassis Kit"
alt="Tamiya 58600 - 1/10 TT-02 Type-S Chassis Kit" title="Tamiya 58600 - 1/10 TT-02 Type-S Chassis Kit"
1 Reviews
Write a review
The Type-S Kit produced by Tamiya in 1/10 scale with TT-02 chassis AWD drivetrain assembly kit, is classified in R/C Models - On-Road - Touring Cars - Electric Powered
  • This is the TT-02 Type-S Chassis, which builds upon the shaft-driven efficiency of the original TT-02 4WD platform and provides it with new suspension parts plus other race-proven features. This enhanced version of the TT-02 is the perfect chassis for hobbyists looking to make the step up from beginner-level chassis to more advanced set-ups. This is the perfect entry level kit for hobbyists looking to enter club level R/C racing and it&39;s perfectly suited for the Tamiya Championship Series in the Spec GT class intended for entry level racers.

    The TT-02 chassis platform is the successor to the TT-01 as it incorporates many new features to make it even easier for the new R/C kit builder to assemble and learn from. The TT-02 chassis performs well as cornering and overall speed has been enhanced to take advantage of new electronics available on the market. In addition to the TT-02 being an ideal platform to start from, R/C hobbyists can expand its potential by adding many of the Ho-Up-Options available to increase the cars speed and performance.

Featured Components:

  • 3mm thick Front/Rear FRP Damper Stays (NEW part)
  • Metal Suspension Mounts (NEW part)
  • Item 51297 Reversible Suspension Arms (Long)
  • CVA Oil Shocks
  • Turnbuckle Shaft Front/Rear Upper Arms
  • Turnbuckle Shaft Steering Tie-Rods
  • Type 540 Torque Tuned Motor
  • Item 51023 Medium-Narrow Racing Radial Tires
  • Metal Cup Joints Metal Drive Shafts
  • Die Cast Aluminum Hex Wheel Hubs

Specifications:


  • Scale 10-Jan
  • Construction type: Assembly kit
  • Terrain use: On-Road
  • Drive-train: 4WD
  • Drive type: Gearbox
  • Drive line: Dog bone
  • Differential type: Gear
  • Suspension: Fully independent double wishbone
  • Steering mechanism: Bell-crank
  • Shock damper: Oil-filled damper
  • Shock damper material: Plastic
  • Tire type: Rubber
  • Tire tread: Radial
  • Body material: Not included
  • Chassis material: Plastic
  • Electronic Speed Control (ESC): Not included
  • ESC model: N/A
  • LED Light buckets: No
  • LED lights: No
  • Motor: 540-brushed type
  • Bearings: Shielded ball bearing
  • Adjustable camber: Yes
  • Adjustable toe angles: Front only
  • Adjustable ground clearance: Yes
  • Adjustable gear ratio: Yes
  • Adjustable wheelbase: Yes
  • Adjustable track width: Fixed
  • Adjustable shock angle: Yes
  • Special feature 1: Item 51297 Reversible Suspension Arms (Long)
  • Special feature 2: 3mm thick Front/Rear FRP Damper Stays
  • Special feature 3: Type 540 Torque Tuned Motor
  • Special feature 4: Metal Cup Joints Metal Drive Shafts
  • Special feature 5: Die Cast Aluminum Hex Wheel Hubs
  • Special feature 6: Turnbuckle Shaft Front/Rear Upper Arms
  • Special feature 7: Item 51023 Medium-Narrow Racing Radial Tires
  • Special feature 8: Rear toe-in is set to 3 degrees.
  • Special feature 9: Metal Suspension Mounts
  • Special feature 10: Torque Tuned Motor
  • Requires A: 7.2 battery & charger
  • Requires B: 2-channel radio gear & electronic speed control
  • Requires C: Motor
  • Requires D: Polycarbonate paint



Product Reviews

1 Reviews

rating
Bought this kit just for fun, to try out onroad racing in basic club racing after 6 years of 4WD Buggy class. It turned out to be a very competitive kit on carpet even in 17.5T class. Body roll and weight are disadvantage, but on shorty pack it made a pod
