Tamiya 58650-60A - 1/10 Volkswagen Beetle Rally VW (MF-01X) (w/o ESC)  [58650-60A]

Tamiya 58650-60A - 1/10 Volkswagen Beetle Rally VW (MF-01X) (w/o ESC)

Price:

USD$94.50

Brand:
Tamiya
Model:
58650-60A
Condition:
Brand New
Write a review
The Volkswagen Beetle Rally VW MF-01X w/o ESC produced by Tamiya in 1/10 scale M-Chassis Car series AWD drivetrain assembly kit, is classified in R/C Models - Off-Road - M-Chassis Cars

Bug Rally!

Production of the Volkswagen Beetle (Type 1) began in 1949 and thanks to its distinctive rounded form with no-frills interior, it became a familiar sight across the world. Powered by a rear-mounted flat 4 engine, the lightweight Beetle offered superlative reliability and uncomplicated upkeep, which helped make the car a fixture on the global rally circuit from the 1950s through to the 1980s. This R/C model assembly kit is inspired by such rallying Beetles. Its lightweight polycarbonate body artfully captures the Beetle form, with metal-plated parts recreating bumpers and side mirrors. Stickers and light pod parts give the model a rallying air.


MF-01X – Compact 4WD At Home on a Range of Surfaces

Based around a tough monocoque frame with integrated gearboxes, this compact 4WD chassis gives a thrilling drive whether you take it on road or flat dirt surfaces. It features a rear-mounted motor, with gear-driven rear wheels and a propeller shaft taking power to the front. Both front and rear gearboxes have differential gears. The battery pack location in the chassis center secures excellent balance, while 4-wheel independent double wishbone suspension employs friction dampers. Off-road capable M-05Ra chassis uprights and hub carriers, plus rally block tires are also included.


The MF-01X chassis offers three different wheelbases. This model uses the L (239mm) setup.

Power from the rear-mounted motor is provided by gear to the rear diff, and propeller shaft to the front.

4-wheel independent double wishbone suspension is cushioned by friction dampers.

Rally block tires are on hand to provide great grip, even on potentially slippery dirt surfaces.


Specifications:

  • Length: 397mm, Width: 163mm, Height: 151mm
  • Wheelbase: 239mm (L)
  • Tire Width/Diameter (Front & Rear): 26/60mm
  • Tread (Front & Rear): 138mm
  • Monocoque Frame
  • Shaft-Driven 4WD
  • 3-Bevel Differential Gears
  • 2-Piece Steering Tie-Rod
  • 4-Wheel Double Wishbone Suspension
  • Front & Rear Friction Dampers
  • Gear Ratio = 9.5:1
  • Type 540 Motor
  • Electronic Speed Controller (sold separately)


Separately Required Items:

  • 2-Channel R/C Unit with ESC
  • Battery Pack & Charger
  • R6/AA/UM3 batteries for transmitter
