XRAY 300021 T4 2015 Specs  [XR-300021]

XRAY T4

2018 All-new Specs

• All-new ULP (Ultra Low Profile) shocks with 4mm lower design for improved stability
• All-new ultra-low profile ULP shock towers to accommodate brand new ULP (Ultra minimal Profile) shocks
• All-new chassis design with new motor mount dish place for further flex adjustment and motor moved more to center
• All-new top redesigned top deck works together with the brand new layshaft bulkheads and motor mount which moves motor more to center
• All-new motor mount dish features new extra rearmost holes for improved traction and additional flex adjustment
• All-new motor mount decreases the framework roll with motor place more to center
• All-new in-line framework flex set-up options
• All-new ECS drive shafts are 51mm miss optimized steering and stability

General

• Designed for greatest performance anyway degrees of racing
• Chassis made to offer maximum traction and steering
• Reduced sensitiveness to changing track conditions, providing super-consistent performance during runs
• EFRA, ROAR, FEMCA spec compliant for stock and modified racing
• Super simple to build, create, maintain, and drive
• Developed, designed and styled by Martin Hudy, produced exclusively by XRAY in European countries on earth's most advanced RC production facility
• Revolutionary on-road platform because of the benchmark for premium quality, reliability and performance
• Premium, professional, high-competition model racing automobile the most demanding racers
• Manufactured from premium European materials, machined making use of advanced Swiss and German machines
• Premium XRAY solution & support


Chassis

• Graphite chassis CNC-machined from 2.2mm premium-grade graphite material
• Chassis specifically made for different track conditions, providing improved traction, steering, security, and increased cornering speed
• Chassis has pre-drilled holes for ARS system
• Chassis features pre-drilled holes for optional parts such as for example framework loads, graphite engine guard, graphite adjustable battery pack owner, and battery strap
• Chassis created designed for brushless engines and LiPo batteries; composite battery pack holders prevent batteries from relocating crashes
• Top deck allows installation of optional aluminum stand to alter flex faculties, and optional graphite steering system plate
• Bulkheads are strategically placed near the center for the chassis to improve steering, traction, and stability
• Layshaft bulkhead enables removal of top deck attachment screws (bearing is held by layshaft bulkhead)
• Upper bulkhead clamps function 4 optimized roll center positions
• Front & rear bulkheads enable separate front & rear diff height adjustment and belt stress adjustment
• 3mm super-low profile shock towers lower the CG and improve stability
• Motor mount bulkhead is compatible along with industry-standard brushless motors
• Centered layshaft and split bulkheads offer enhanced balance because of maximum fat distribution of motor towards centerline, giving faster left-right transitions
• Motor mount bulkhead is along with layshaft bulkhead in 1 solid piece to remove tweak brought on by connected screws
• Motor mount bulkhead is connected with aluminum engine mount dish to get rid of tweak, offers multiple flex adjustment possibilities by adding/removing screw ahead or behind the nut, or by utilizing optional post instead of the nut
• The motor mount plate is linked to the chassis via an M3 nut and an additional countersunk screw is placed ahead or behind the nut if more reinforcement becomes necessary, or the nut are eliminated and 1 or more of 6 holes can be utilized as additional flex adjustment options
• Front & backside lower bulkheads take care of the anti-roll bar bearing mounting system

Suspension

• Kit includes both standard & ARS (Active back Suspension) back suspensions
• ARS suspension system offers great adjustment possibilities and driving characteristics
• ARS suspension is composed of ARS hands, graphite 0° C-hubs for optimal flex characteristics, hard suspension system block, ARS suspension system block, and ARS linkage connecting the holder towards suspension block
• ARS linkage angle – modified by adding/removing shims on the steering block and ARS-holder – modifications the toe-in characteristics regarding the back tires during framework roll
• Aluminum suspension holders featuring built-in Suspension Settings (ISS) for fast & effortless suspension system geometry adjustment
• Suspension holders enable stronger mounting associated with suspension system hands, and so the suspension geometry of this vehicle doesn't change even with hard crashes
• Suspension mounting system permits very free arm motion, which gives greater traction, smoother driving, and enhanced steering
• Suspension holder system enables suspension hands to be installed independently from bulkheads allowing for elongated chassis flex to generate more traction
• Independent suspension holders allow for more precise and fine set-up corrections via different bushings
• Rear suspension aluminum holders function incorporated toe-in
• C-hubs available optionally in standard caster angles (0°, 2°, 4°, 6°); available in four hardnesses (M – medium, H – difficult, G – graphite and aluminum)
• Hard front steering obstructs increase steering reaction, decrease front side tire overheating in high-traction conditions
• Small, robust steering obstructs created from special proprietary composite product, available optionally in 3 hardnesses (M – medium, H – hard, G – graphite and aluminum), and have 2 Ackermann positions
• Rear uprights give increased security; available optionally in 3 hardnesses (M – medium, H – hard, G - graphite)
• Rear uprights function integrated 0° toe-in to stop suspension geometry changes in severe crashes
• Arms function innovative SFATM (Suspension Flex modification), innovative and unique graphite stiffeners allow for super-quick suspension system flex adjustment to effortlessly adjust the traction associated with automobile under different track conditions
• Suspension hands feature incorporated anti-roll club mounts; rear hands function 3 different anti-roll bar mounts for super-fine adjustment of back anti-roll bar
• Suspension arms produced from graphite product for improved traction and security for the car
• Anti-roll bar system is installed toward bulkheads via bearings for extra-smooth movement and maximum accuracy, and part play is eradicated by aluminum bushings
• Anti-roll club height is adjustable via easy screw adjustment… quick & easy
• Front 1.4 mm & rear 1.3mm anti-roll bar wires included
• Easily-adjustable wheel offset utilizing optional wheel hubs (-0.75mm, +0.75mm, +1.5mm)

Drivetrain

• Lightweight center layshaft CNC-machined from aircraft aluminum
• 84T 48P spur gear – extra-hard product, wobble-free design
• 38/20T (1.9) interior gearing for efficient, superior drivetrain
• Premium-qualitydrive belts
• C-hubs with big openings for fast & easy assembly/disassembly of CVDs and ECS drive shafts; prevents collision of CVD or ECS drive shafts with C‑hub in serious crashes
• Super-light drive axles
• Front Extra-Strong ECS drive shafts equalize the speed between your drive shaft and wheel. With an original 2-piece joint between the axle therefore the wheel, any extreme wheel turning angle is split into two shallower angles without joint binding. Which means that regardless of the cornering speed and wheel angle, the inner wheel will not bind or vibrate. Drive through corners is more stable, more exact, and easier to drive
• ECS drive shafts made from world-renowned, self-developed HUDY Spring Steel hand ground for maximum precision
• Super-lightweight Swiss 7075 T6 aluminum back drive shafts (50mm), hard-anodized, color-coated and laser-engraved, 38% lighter than standard drive shafts
• Super-lightweight wheel axles constructed from premium HUDY Spring Steel
• 7075 T6 aluminum wheel hubs
• Complete pair of high-speed, blue-sealed ball-bearings are degreased and gently oiled for maximum efficiency, separately controlled, chosen, and inspected
• Aluminum self-locking wheel nuts

Differentials

• Super-smooth, super-light maintenance-free composite gear differential
• Adjustable gear differential stiffness via oil viscosity
• Super-light composite Front Solid Axle with XRAY’s own smart quick-change outdrive system for simple outdrive change; no servicing or replacement of drive shaft blades needed, translates into reduced servicing costs

Steering

• Servo mounting system for improved stability and reduction of unwanted tweak
• Servo mount permits the servo to be suspended into the framework centerline, providing better stability while eliminating tweak and making it possible for extra traction
• Steering is isolated from framework flex, ensuring tweak-independent steering for super-precise and consistent steering characteristics
• Servo mount and graphite servo holder are installed to the framework with 3 screws and 2 centering articles to remove the possibility of servo motion under hard crashes
• Servo mount includes extra gap where in fact the battery backstop screw can be mounted
• Servo mount includes additional gap for in-line flex modification system

Shocks

• Ultra- minimal Profile (ULP) aluminum shocks even for reduced CG and improved stability
• ULP aluminum shocks are reduced by 4mm comparing to SLP shocks to deliver maximum stability under all track conditions, while reducing traction roll under high-traction conditions and also to make the automobile better to drive
• Shock shafts are particularly hardened for maximum strength
• Foam inserts for perfect surprise rebound
• Super brief Shock Springs (4S) developed & designed for the SLP shocks

• C2.5 springs within the kit to match ULP shocks plus the spring rates are optimized to supply maximum steering and traction
• XRAY self-developed and manufactured 4S springs are by hand chosen for optimum precision, equal size, and equal damping faculties
• Race-tested and tuned surprise roles

Bumper & Body Mounts

• Front upper and lower composite bumper made from specially-formulated material to withstand difficult impacts
• Super low-profile foam bumper created from lightweight, high-resilience foam
• Foam bumper is bigger for perfect human anatomy fit
• Foam bumper is manufactured out of strong but lightweight material for improved durability but keeping the extra weight as low as possible
• Composite bumper top holder brace helps reduce chassis breakage in hard crashes

Assembly, Set-up, Support

• Premium 3D full-color Instruction Manual & supplementary sheets
• To completely understand the set-up possibilities we recommend the famous HUDY Set-up Book (available for download solely at www.hudy.net) that will be loaded with over 50 pages of top-notch images and easy-to-understand RC car set-up explanations
• Exclusive Virtual on line Setup Sheet database with 1000s of set-up sheets for race songs across the world
• Premium, unmatched XRAY online help

Adjustment Possibilities

• Fully-adjustable front side and rear suspension geometry: caster, camber, toe, anti-dive, anti-squat, ride height, droop, track-width, roll center, wheelbase
• Adjustable gear differential tightness via oil viscosity
• Four various upper linkage positions on top bulkhead clamps
• Roll center height adjustment via shims on upper bulkhead clamps
• Adjustable front and back belt-tension control utilizing quick-adjust system incorporated into bulkheads
• Front and back diff height modification making use of quick-adjust system integrated into bulkheads
• Adjustable HUDY aluminum turnbuckles (steering, front & back top links, ARS)
• Multiple top and lower surprise mounting areas at front and rear
• Adjustable Ackermann and bump steer
• Pre-drilled chassis locations for optional framework weights in center of chassis
• Adjustable front side and rear anti-roll bars
• Chassis pre-drilled holes for fat stability adjustment
• Adjustable in-line flex system
