XRAY 370007 X12 2018 EU Specs [XR-370007]

Price:

USD$344.20

Brand:

XRAY

Model:

XR-370007

Not Available

Please kindly input your name and email address, we will inform you once we have the restocking.

Or you may find similar product under the
R/C Models - On-Road - Pan Cars category

Write a review

alt="XRAY 370007 X12 2018 EU Specs" title="XRAY 370007 X12 2018 EU Specs"

Description

The X12 2018 EU Specs produced by XRAY in 1/12 scale X10 / X12 series RWD drivetrain assembly kit, is classified in R/C Models - On-Road - Pan Cars

Dimensions

Class: 1/12 electric pan car
Width: Adjustable 167mm +/- 2mm front side, 169mm rear
Length: 264mm (varies depending on rear tires used)
Wheelbase: 201 +/-0.5mm
Weight: 202 g
Ready-to-run fat: 840 g - incl. BL system (varies based on equipment used)

Chassis

Chassis: EU edition - 2.5mm carbon fibre, CNC machined; United States version - 2.0mm Swiss 7075 T6 aluminum, CNC machined
Body: maybe not included, utilizes 1/12 pan automobile kind

Drivetrain

Type: 2WD direct drive to rear axle
Rear Axle: Graphite shaft with ball differential
Primary: Spur/pinion
Bearings: High-speed ball-bearings (10)

Suspension

Front: Spring-supported, kingpin-style front suspension system with upper & reduced suspension system arms and steering blocks
Rear: Articulating rear engine POD adjustable via pivot-ball links, managed by rear surprise absorber.
Rear Shock: Central adjustable oil-filled surprise absorber

Geometry

Ride Height: Adjustable front + rear
Wheelbase: Adjustable
Camber Adjustable front
Front Caster (Static): 114.5° fixed adjustable static caster
Front Caster (Reactive) 2.57.5° adjustable reactive caster
Track-width: Adjustable front and rear
Toe: Adjustable front
Downstop: Adjustable rear
Ackermann: Adjustable with shims
Bumpsteer: Adjustable with shims
Steering: Direct linkage between steering servo saver and steering obstructs
Balance: Front/rear fat balance adjustable via battery pack place

Other

Wheels: Not included
Tires: perhaps not included
Instructions: Full-color Instruction Manual with 3D graphics
Set-up book: Printed version not included. Latest full-color Set-up guide (16 pages) could be downloaded from XRAY internet site. Set-up Book shows past XRAY models in photographs contained within it, though the methodology and set-up concept are exactly the same for several 1/12 pan vehicles.
Packaging: Carton package with plastic bags with parts
Additionally included: HUDY Diff Grease, Authentication Certificate, parts list & exploded view, decals, oils
Not included: Motor, batteries, rate controller, tires, body, steering servo, radio gear, tools

Remark :

Due to limited stock availability, please notice that some XRAY items may have to order from the factory and the ready time is around 4-6 weeks. Customer purchases the item is assumed to accept the waiting time which allows us to order directly from the manufacturer if the item is out of our warehouse.
