The X1\'20 produced by XRAY in 1/10 scale RWD drivetrain assembly kit, is classified in R/C Models - On-Road - Formula Cars



XRAY X1

1/10 LUXURY ELECTRIC FORMULA



2018 All-new:

  • All-new super-narrow framework design is 24mm narrower to eliminate framework connection with the track while rolling
  • All-new redesigned part website link adaptors – machined from graphite – are installed to aluminum stands to work well with new super-narrow chassis
  • All-new steering obstructs with new additional Ackermann place for more in-corner steering and nearly 100percent Ackermann curve
  • All-new surprise adaptor for quick & simple surprise position changes; new frontward position for improved drivability over bumps and enhanced on-power traction
  • All-new graphite servo owner enables mounting of new surprise adaptor
  • All-new tweak-free pivot brace for faster & easier pod dish mounting
  • All-new back link brace with longer leads for battery side end permits 5mm adjustment of battery position
  • All-new battery backstop mounting allows battery position adjustment
  • Current most useful doing 1/10 formula automobile: 2x European Champion, 3x ETS Champion, Snowbird Champion, IIC Champion, and dozens of nationwide championship titles
  • Platform (including virtually all components) works with past X1 versions
  • 2018 version focused on fine improvement of little details, making the automobile a complete winner right out from the box



General:

  • XRAY 1/10 Formula race automobile with authentic 100% self-developed XRAY components, designed and manufactured components by XRAY in Europe
  • Legendary XRAY premium design, workmanship & product quality and unmatched focus on the finest details
  • Simple yet effective and proven design, well thought-out details, unmatched accuracy in every details
  • High-competition design with consider ultra-low fat, resulting in super-lightweight construction
  • Optimized for interior carpet race plus outdoor asphalt racing
  • Elegant in simpleness & effectiveness, the X1 is scheduled to end up being the brand new standard in 1/10 Formula racing



Chassis:

  • CNC-machined from custom-manufactured 2.5mm high-grade graphite product with a specially-designed element for carpeting race and asphalt racing
  • Super-narrow framework front side allows for maximum traction while keeping sufficient steering and cornering speed
  • Chassis design has optimal tightness for excellent managing, freedom for optimum traction, and ideal torsional stability
  • Superb handling on either indoor or outdoor songs, on carpeting or asphalt
  • Improved steering reaction and optimal side-to-side weight transition
  • Rear graphite brace holds battery set up, and a solid mounting base for the optional part shock
  • Battery positioning may be quickly changed from inline to cross-chassis, available ideal weight balance depending on track conditions; composite battery backstops minimize battery motion
  • Cross-chassis battery pack positioning has adjustable place around 5mm besides thanks to the adjustable battery backstop within the chassis
  • Laydown steering servo orientation for cheapest CG at chassis center
  • Front center shock mount is positioned inside absolute chassis center for perfect side-to-side fat transfer
  • Chassis and back pod function pre-drilled centerline holes for maximum fat stability modification making use of HUDY Balancing Tool #107880



Front suspension:

  • Strong, simple, completely adjustable, yet smart and ultra-efficient front side suspension system
  • High-grade graphite reduced & upper suspension system arms and arm mount plate
  • Tiny, strong composite pivot balls for smooth, bind-free operation
  • Adjustable front side caster via eccentric bushings for front top dish:  3°, 6°, 9°, and 12°
  • Adjustable front camber via eccentric bushings for front upper arms:  1.0°, 1.5°, 2.0°, and 2.5°
  • Front adjustable anti-roll club with optional complete selection of cables for fine tuning
  • Adjustable front upper & reduced roll facilities via included shims
  • Adjustable front track-width modification via included wheel axle shims



Steering:

  • Independent floating servo mounting system: range of separate or fixed position
  • Tiny, robust 4-spring servo saver protects the servo from effect damage. Provides exact steering and constant maneuvering, while making the automobile easier to drive
  • Pre-drilled chassis holes to accommodate either a micro or mid-size steering servo
  • Centralized servo position for perfect steering traits
  • Centrally-positioned servo saver arm with selectable Ackermann positions
  • Servo supply mounting: range of independent floating or standard mounting
  • Adjustable bumpsteer characteristics via included shims
  • Steering backstops installed on lower hands enable adjustment of optimum steering angle
  • Super-tiny yet robust steering blocks with additional new Ackermann positions for lots more steering, and ultra-precise inner opening for kingpin guarantees wobble-free assembly
  • Super-smooth hardened metal kingpins
  • Adjustable, lightweight aluminum turnbuckles for front toe adjustment



Rear pod:

  • Compact, ultra-lightweight back pod design with composite rear pod links positioned closer to chassis centerline
  • Narrow rear pod design provides improved steering reaction and optimal side-to-side fat transition
  • CNC-machined pod bulkheads created from premium extra-hard Swiss 7075 T6 aluminum, additionally black coated for long life and stylish look
  • Rear pod top plate made from strong graphite dish is the base the main shock, the platform the side tubes, plus it connects leading framework assembly utilizing the rear pod
  • Rear wing graphite mount features multiple wing height mounting jobs for even better adaptation to various traction conditions
  • Smart pod design accommodates all motors, permits super-easy motor access
  • Pod pivot brace features an ultra-small and lightweight pivot ball for smooth movement
  • Eccentric composite bushings are included for ultra-fine back trip height adjustment
  • Lateral damper part pipes for smoother, more constant operation
  • Linear side springs for consistent and smooth compression for smooth out-of corner exiting, and reduced total of traction rolling



Shock:

  • Well-proven brief surprise from T4 touring vehicle platform.
  • Interchangeable internal parts, with fixed 1-piece accuracy pistons that are available with 3 different-diameter holes for damping adjustment: 1.1, 1.2, and 1.3mm with 3 and 4 holes
  • CNC-machined Swiss 7075 T6 aluminum shock human anatomy, hard-anodized, with fine external threading for quick & effortless surprise springtime preload adjustment
  • Super-soft silicone shock O-ring for smooth procedure while preventing oil leakage
  • Ultra-finely completed hardened surprise shaft
  • Self-centering shims support the shock O-rings, for perfect positioning in surprise body
  • Finely-threaded aluminum surprise reduced cap secures the silicone O-rings and shims in shock body
  • Super-soft silicone membrane, supported by a miniature foam pad, provides proper damping characteristics
  • Aluminum shock springtime collar allows quick & easy downstop adjustment
  • The C=2.3 linear 3S shock springtime provides the most readily useful balance between traction, security, and steering reaction; a total range of optional springs can be obtained for further fine adjustment
  • Complete array of springs including modern 3S springs (optional)
  • Aluminum modern shocks system for improved traction & steering (optional)
  • New adaptor enables long shock mounting for improved traction and better driving over bumps



Drivetrain:

  • CNC-machined ultra-precise wheel axles created from premium HUDY Spring Steel™ are furthermore hardened and hand-ground for precision fitment
  • Ultra-strong lightweight hollow steel axle for optimum dependability and paid off rotational weight
  • Rear differential with high-grade precision carbide balls for spur gear, hardened & precision-ground D-shaped steel shims, and premium carbide axial thrust-bearing
  • Precision-molded spur gear created from XRAY's exclusive composite material, guarantees real running, super-quiet procedure, and robustness to be used with effective motors
  • CNC-machined rear hubs made from lightweight aircraft aluminum, specifically lightened and black-coated for stylish looks
  • Rear left aluminum wheel hub features a center-balanced clamping mounting system, ensuring secure mounting while eliminating vibration and run-out
  • Full set high-speed, blue-sealed, steel ball-bearings utilized through the drivetrain and steering to ensure maximum efficiency. All bearings are degreased and oiled with AeroShell® Fluid 12 for maximum smoothness and long life
  • Easy back track-width adjustment via included shims





Body & Aerodynamics:

  • Robust human anatomy articles mounted on the solid platform on aluminum stands, featuring fully-adjustable body holders
  • Multi-part front side spoiler consist of composite bumper and Lexan™ downforce spoiler
  • Composite front chassis bumper is extremely rigid yet versatile to supply superior protection
  • Lightweight Lexan™ front spoilers – choice of low or high downforce spoilers for huge difference track conditions
  • High-efficiency, high-strength, adjustable-downforce back wing with adjustable mounting height position
  • High-performance, low-profile aerodynamic X1 human body produced from top-notch premium Lexan™ material for maximum flexibility generally in most track conditions. Back air networks direct airflow onto back wing. Body sides in addition to cockpit sides are as flat as you can to direct airflow round the human body for optimum stability. In the rooftop, two flow channels are included for proper ventilation. An integral helmet ensures the body is legal for events where a pilot figure helmet is required.



Installation & support:

  • Highest quality of all of the composite parts ensures super-precise fitment, simple assembly, and smooth procedure of all parts
  • Premium 3D full-color Instruction Manual
  • Exclusive Virtual Online Set-up Sheet database with 1000s of set-up sheets for competition tracks across the world
  • Premium, unmatched XRAY online support



Modification possibilities:

  • Front camber, caster, and toe
  • Front & back track-width
  • Front, center, and back ride height
  • Front springs
  • Front anti-roll bar
  • Fully-adjustable back surprise absorber
  • Downstops
  • Side damper pipes for lateral pod damping
  • Chassis tweak
  • Ackermann
  • Bump steer
  • Differential settings
  • Battery position
  • Front wing downforce
  • Rear wing downforce
  • Steering system
  • Servo mount system



Dimensions

Class:

1/10 formula

Width:

Adjustable 180mm front, 185mm rear (will depend on tires utilized)

Lenght:

410mm

Wheelbase:

264mm

Weight:

375g

Ready-to-run fat:

985g (varies depending on gear utilized)

Chassis

Chassis:

2.5mm carbon fiber, CNC machined

Body:

XRAY X1 1/10 formula kind


Drivetrain

Type:

2WD direct drive to rear axle

Back Axle:

Steel shaft with ball differential

Primary:

Spur/pinion

Bearings:

High-speed ball-bearings (13)


Suspension

Front:

Spring-supported, kingpin-style front suspension system with composite  steering blocks and graphite top & lower suspension arms

Back:

Traditional back pod, adjustable via pivot-ball links, controlled by part tubes

Rear Shock:

Central adjustable oil-filled surprise absorber


Geometry

Ride Height:

Adjustable front + back

Camber:

Adjustable front side

Front Caster:

3–12° adjustable caster

Track-width:

Adjustable front + rear

Toe:

Adjustable front side

Downstop:

Adjustable front side + back

Anti-roll club:

1.2mm front

Ackermann:

Adjustable with servo saver arm and steering block

Steering:

Direct linkage between steering arm and steering obstructs

Balance:

Front/rear fat balance adjustable via battery position


Other

Wheels:

Maybe not included

Tires:

Perhaps not included

Guidelines:

Comprehensive colour instructions

Packing:

Carton box with vinyl bags with components

Additionally included:

Lexan Formula human anatomy & front wing, HUDY Diff Grease, Authentication Certificate, parts list & exploded view, surprise oil

Perhaps not included:

Radio system (transmitter and receiver), steering servo, engine, pinion gear, battery pack, rate controller, charger, tires, tires, inserts, high-strength fibre tape, double-sided tape, CA glue, bearing oil, tools







Remark:
Due to limited stock availability, please notice that some XRAY items may have to pre-order from factory and the ready time is around 2-4 weeks. Customer purchases the item is assumed to accept the waiting time which allows us to order directly from the manufacturer if the item is out of our warehouse.
