Description

The M18 PRO LiPo 4WD Shaft Drive Micro Car produced by XRAY in 1/18 scale M18 / M18Pro / M18T / M18MT series AWD drivetrain assembly kit, is classified in R/C Models - On-Road - Touring Cars - Electric Powered

Dimensions

Class: 1/18 electric micro car
Front Width: 100 mm (adjustable with offset wheel axles)
Rear Width: 107 mm
Length: 220 mm
Wheelbase: 150 mm
Weight: 165 g
Ready to perform fat: 440 g

Chassis:

Chassis: LiPo optimized chassis CNC-machined from premium 1.6mm carbon fiber
Upper deck: revolutionary XRAY Multi-Flex tech top deck enables independent front/rear flex adjustment
Body: 150 mm micro human body (included)

Drivetrain:

Type: shaft-drive 4WD
Drivetrain: aluminum main driveshaft
Primary drive: pinion/spur
Drive ratio: 1:2.5
Drive shafts: composite front side + back
Differentials: composite ball differentials - adjustable front + rear
Bearings: 20 high-speed ball-bearings

Suspension:

Front: completely separate
back: fully independent
Dampening: friction-type coil-over shocks

Geometry:

Camber: front/rear: -1° (preset)
Caster: 6° (preset)
Front Toe: preset +0.5° (adjustable)
back Toe: preset 2.5° (adjustable)
Downstops: adjustable front side + rear
Anti-roll bars: not included
Wheelbase: 150 mm

Others:

Wheels: touring car-style hex hub wheel mounting system
tires: mounted foam tires 50sh front side, 35sh back
guidelines: full-color manual with 3D images
Packing: carton package with 8 vinyl bags with parts
Packing: certificate, parts list & exploded view, set-up sheet, decals, driveshaft set up tool, hex hub assembly tool
Not included: radio system (transmitter & receiver), steering servo, ESC, engine, LiPo battery pack, battery charger, CA glue, Lexan paint, transmitter batteries, 3.0mm phillips screwdriver, 1.5mm allen wrench
